  • PUZZLE-IN004  [ KC인증 ]

    Overview

    ● Intel® Xeon D-2100 series processor (Skylake-D) with optional Intel® QAT
    ● Support eight GbE RJ-45 via Intel® I211-AT, four 10 GbE SFP+ and IEI networking module
    ● 8 x 288-pin RDIMM DDR4 2666MHz, RDIMM up to 256GB / LRDIMM up to 512GB
    ● 1 x RJ-45 Console, 1 x USB 3.2 Gen 1 (5Gb/s), 1 x USB 2.0, LCM
    ● 2 x 2.5” SATA drive bay, 2 x M.2 M key for nVME,1 x PCIe Mini with SIM card
    ● Support one PCIe 3.0 x8 slot, one PulM module slot
    ● Redundant PSUs
    ● Support open source software, such as pfSense® and OPNsense®.
    제품정보 바로가기
  • PUZZLE-IN003B  [ KC인증 ]

    Overview

    ● Intel® Atom® C3558/3758 processor
    ● Support 6 x 1 GbE and 2 x 10 GbE SFP+ via X553 integrated in C3558/C3758
    ● DDR4 2133MHz ECC (by CPU) or non-ECC UDIMM/R-DIMM Up to 128GB
    ● 1 x M.2 A key (USB 2.0, PCIe x1), 1 x miniPCIe (USB 2.0, PCIe x1) with SIM card slot
    ● 1 x M.2 M key for PCIe 3.0 x4 nVME, 1 x eMMC 32GB
    ● Support open source software, such as pfSense® and OPNsense®.
    제품정보 바로가기
  • PUZZLE-IN001  [ KC인증 ]

    Overview

    ● Intel® Xeon® E, 8th Generation Intel® Core™/Pentium®/Celeron® Processor
    ● Support 8 x GbE RJ45 via Intel® I211, and two IEI Network Module
    ● 2 x 288-pin Long DIMM, DDR4 2100MHz ECC & non ECC, up to 32GB
    ● 1 x RJ45 Console, 2 x USB 3.0, LCM
    ● 2 x 2.5” SATA drive bay, 1 x M.2 B-Key (SATA, USB 3.0), 1 x PCIe mini
    ● Support PCIe x4 and PCIe x8 slot
    ● Redundant PSUs
    제품정보 바로가기
  • PUZZLE-IN002  [ KC인증 ]

    Overview

    ● 8th Generation IntelCore. i7/i5/i3, Pentiumor Celeron Processor
    ● Support 6 x GbE RJ45 via IntelI211
    ● 2 x 288-pin DIMM, DDR4 2400MHz Non-ECC/RDIMM, up to 32GB
    ● 1 x RJ45 Console, 2 x USB 3.0, LCM
    ● 1 x 2.5” SSD/HDD Bay, 1 x M.2 A-Key (SATA, USB 3.0), 1 x PCIe mini card (PCIe , SATA)
    ● Support PCIe x16
    제품정보 바로가기
  • PulM NIC Module for Puzzle  [ SAMPLE ]

    Overview

    PulM-10G4SF-MLX

    - Mellanox ConnectX-4 Lx based Network Interface Card support Quad 10GbE with 4 x SFP+ by 2 PCIe 3.0 x 4 Interface



    PulM-10G4SF-XL710

    -Intel® Ethernet Controller XL710-BM1 based Network Interface Card with 4 x SFP+ by 1 PCIe 3.0 x8 interface



    PulM-1G4T-I211

    - Intel® Ethernet Controller I211 based Network Interface Card with 4 x GbE RJ-45 by 4 PCIe 2.0 x2 Interface *with by pass funtion (by sku).



    PulM-1G8T-BCM5720

    - Broadcom BCM5720 based Network Interface Card with 8 x RJ-45 by 4 PCIe 2.0 x 2 Interface

    제품정보 바로가기
  • S2400  [ KC인증 ]

    Overview

    LGA1150 Socket for Intel® Core i7/i5/i3 Processor


    Intel® Q87 Chipset

    4 * 240-pin DDR3 SDRAM DIMMs (Max. 32GB)

    2 * Gigabit Ethernet Controller

    4 * USB3.0  &  8 * USB2.0

    6 * SATA 6Gbps Port (RAID 0, 1, 5, 10)

    Support IPMI 2.0 via iRIS-2400 Module
    제품정보 바로가기
  • S8500(E5)  [ SAMPLE ]

    Overview

    Dual Socket LGA 2011 R3

         support Intel Xeon processor E5-2600 v3&v4 series


    Quad DDR4 2400/2133/1866/1600

         R DIMM AND LR DIMM, 16 * DIMM


    10 * SATA3 6.0 Gb/s, 2 * SATA3 by Marvell 9172

    3 PCIe3.0 * 16, 3 PCIE 3.0 * 8

    Integrated IPMI 2.0 and KVM with Dedicated LAN

    Support 4 * GLAN by Intel i210
    제품정보 바로가기
  • S8500(E3)  [ SAMPLE ]

    Overview

    Supports Intel Xeon processor E3-1200 v3 series &

         Haswell i3 processors


    4 * DIMM DDR3 1600/1333 ECC, (Max.32GB)

    2 * PCIe 3.0 x16, 1 x PCIe 2.0 x4,

        1 * PCIe 2.0 x1, 2 x PCI


    4 * Intel i210, support Quad GLAN

    4 * SATA3, 2 SATA2 by Intel C224 support

        RAID 0,1,5,10


    2 * SATA3 by Marvell 9172 support RAID 0,1

    4 * USB 3.0 ports (2 rear + 2 via header )

    7 * USB 2.0 ports (2 rear + 4 via header +1 Type A)
    제품정보 바로가기
  • S7500(8L/6L)  [ KC인증 ]

    Overview

    6th Generation Intel® Xeon® / Core™

         i7/i5/i3 processors


    4 * DDR4 DIMMs; Max. 64 GB (ECC / non-ECC)

    8 * or 6 * PCI-E GbE ports; 2 Advanced

        LAN Bypass pairs


    Optional IPMI 2.0 module

    1 * CF slot, 1 * Mini PCI-E slot
    제품정보 바로가기
  • S6500  [ KC인증 ]

    Overview

    Supports Single Intel LGA 2011, Supports Intel Xeon

         Processor E5-1600 / 2600 / 4600 & v2 Series


    Intel C602: 2 * SATA3 6.0Gbps, 8 * SATA2 3.0Gbps

        (four from SATA ports, others from mini SAS port)


    Marvell SE9172: 2 * SATA3 6.0Gbps

    2 * PCIe 3.0 x 16, 4 * PCIE3.0 x 8, 1 * PCIE 2.0 x 8

    ASPEED 2300 for BMC controller,

    Intel i210 Support Dual GLAN with teaming function
    제품정보 바로가기
